Monel400 Stainless Steel Square Pipe

Monel alloy, also known as nickel alloy, is an alloy made by adding copper, iron, manganese and other elements to nickel metal as the base. Monel alloy has good corrosion resistance, silvery white color and is suitable for edge wire material.

Product Details

Monel400 Stainless Steel Square Pipe

Monel Alloy

Monel alloy, also known as nickel alloy, is an alloy made by adding copper, iron, manganese and other elements to nickel metal as the base. Monel alloy has good corrosion resistance, silvery white color and is suitable for edge wire material.

Product description

Monel400 stainless steel square tube Monel400 is one of the largest and most versatile corrosion resistant alloy square tube with excellent overall performance. This alloy has excellent corrosion resistance in hydrofluoric acid and fluorine gas media, and also has excellent corrosion resistance to hot concentrated alkaline solutions. It is also resistant to corrosion by neutral solutions, water, seawater, atmosphere, organic compounds, etc. An important feature of this alloy is that it generally does not produce stress corrosion cracks and has good cutting properties.

Corrosion resistance

Monel400 alloy has excellent corrosion resistance to fluorine gas, hydrochloric acid, sulfuric acid, hydrofluoric acid and their derivatives. It is also more resistant to corrosion than copper-based alloys in seawater. Acid media: Monel400 is corrosion resistant in sulfuric acid at concentrations less than 85%. monel400 is one of the very few important materials that can resist hydrofluoric acid. Water corrosion: Monel400 alloy in most cases of water corrosion, not only excellent corrosion resistance, and hole corrosion, stress corrosion, etc. are rarely found, the corrosion rate is less than 0.025mm/a. High temperature corrosion: Monel400 in the air continuous work of the maximum temperature is generally around 600 ℃, in the high temperature steam, the corrosion rate is less than 0.026mm/a. Ammonia: Due to Monel400 alloy has high nickel content, so it can resist corrosion under anhydrous ammonia and ammonia conditions below 585℃.

Pros of Monel

Monel alloys have a great deal to offer. Prior to the 1950s, they were the "go to" choice for many critically important industries. It could also be easily welded, soldered, and brazed. This is because of its:

· high corrosion resistance to acids and alkalis

· high mechanical strength

· good ductility (easy to shape and form)

· resistance to alkalis

· relatively low cost

· availability in different forms including hot and cold-rolled sheets, plates, rods, bars, and tubes

· attractive appearance and finishes, including a gray-green patina similar to copper

Cons of Monel

While Monel has a number of advantages, it is far from the perfect metal. The machinability of these alloys is poor because of their tendency to quickly work-harden. What's more:

· While surface discoloration in the form of a patina may be attractive in some circumstances, it can create problems in others.

· While it is resistant to corrosion, it can become pitted if exposed to salt water.

· While it is corrosion resistant under many circumstances, it can corrode when exposed to certain substances. For example, nitric oxide, nitrous acid, sulfur dioxide, and hypochlorites are all substances that can corrode Monel.

· The presence of Monel can lead to galvanic corrosion. In other words, if aluminum, zinc, or iron are used as fasteners for Monel and then exposed to certain conditions, the metal fasteners will quickly corrode.

Product Introduction of Monel400 Stainless Steel Square Pipe

Item

Stainless Steel Square Pipe

Product nameMonel400 Stainless Steel Square Pipe Manufacturer
Place of OriginShandong,China
Brand NameKuaima
MaterialMonel400
GradeMonel
TypeWelded,Seamless
SizeAccording to customer needs
SurfaceBrushed, Polished, Etched,etc.
Tolerance±1%
MOQNegotiable
ApplicationDecoration,Food Grade,Petroleum, Chemical, Medical, Light Industry, Mechanical Instrumentation, etc.
StandardASTM,AISI,GB,DIN,JIS,EN,etc.
CertificationISO,CE,etc.
Processing ServiceBending, Welding, Decoiling, Punching, Cutting, Moulding
Payment termsL/C,T/T,D/P,etc.(According to customer needs)
Price TermCIF,CFR,FOB,EXW,etc.

chemical composition of Monel400 Stainless Steel Square Pipe

Element Nickel, Ni Copper, Cu Iron, Fe Manganese, Mn Silicon, Si Carbon, C Sulphur, S
Content (%) Remainder 28-34 2.5 max 2 max 0.5 max 0.3 max 0.024

mechanical property of Monel400 Stainless Steel Square Pipe

Properties Metric Imperial
Tensile strength(annealed) 517-620 MPa 75-90 ksi
Yield strength 172-345 MPa 25-50 ksi
Modulus of elasticity 179 GPa 26000 ksi
Poisson’s ratio 0.32 0.32

Product Applications of Stainless Steel Square Pipe

This alloy has a combination of strong and corrosion-resistant properties and is widely used in chemical and other industries. For example, it is used in the manufacture of heaters, heat exchangers, evaporators, distillation kettles, distillation towers, condensers for fatty acid processing, equipment for processing rosin pavilion acid, chemical pumps, etc. Since the alloy also has high strength and good oxidation resistance at high temperatures, it can also be used in the heat treatment industry to manufacture various structural parts. In the nuclear power industry, the alloy has good corrosion resistance to high temperature and high pressure water, so it is also an important structural material used in light water reactor nuclear power plants, and the products are plates, bars, wires, strips, tubes.
