Structural steel plate is a type of carbon steel plate with a carbon content of up to 2.1% by weight. Structural plates are commonly used in the manufacture of building materials and structures, where weight reduction and durability are both important factors.
Structural steel plates (mechanical engineering materials): are steels that meet specific strength and formability grades. Formability is expressed as elongation after interruption of the tensile test. Structural steel is generally used for applications such as load-bearing, where the strength of the steel is a reuse design criterion. Structural steel is one of the special steels.
1.Steel used as parts of various machines. It includes carburized steel, tempered steel, spring steel and rolling bearing steel.2. Steel used for engineering structures. It includes carbon steel in A, B, special steel and ordinary low-alloy steel.
HIGH TENSTILE PLATES | CHEMICAL PROPERTIES | PHYSICAL PROPERTIES | ||||||||
C | Mn | S | P | Si | Y.S (Mpa) (Min) | UTS (Mpa) (Min) | El (%) | IMPACT (Min) | ||
INDIA | SAILMA 350/350 HI | 0.20 | 1.50 | 0.040 | 0.040 | 0.50 | 355 | 490-610 | 21 | 40J at 0°C |
SAILMA 410/410 HI | 0.20 | 1.50 | 0.040 | 0.040 | 0.50 | 410 | 540-660 | 20 | 35J at 0°C | |
EUROPE | EN 10025 S355J2G3 | 0.20 | 1.60 | 0.035 | 0.035 | 0.55 | 355 | 490-630 | 19 | 27J at -20°C |
CHINA | Q 345 | 0.20 | 1.00 - 1.60 | 0.040 | 0.040 | 0.55 | for thk<16mm-345, | 470-630 | 22 | 34J at -20°C |
GERMANY | ST 52.3 | 0.20 | 1.60 | 0.040 | 0.040 | 0.55 | 355 | 510-680 | 22 | 27J at -20°C |
Grade | EN10025-3, EN10025-2, EN10025-6, EN10025-4 |
Width | 2m, 2.5m, 1.5m, and 3m |
Length | 6 meter to 12 meter |
Ultra High Yield Plates | BSEN 10025 S275J2+N BSEN 10025 S275JR+AR BSEN 10025 S235JR+AR BSEN 10025 S355K2+N BSEN 10025 S355JR+AR |
Thickness | 6 milimeter to 300 milimeter |
1. The structure of buildings, Bridges, railway station
2. The piping components and manufacture of industrial equipment
3. The construction of the automobile body, warehouse, container
4. Commercial electrical appliances, etc
