Product Description

Titanium wire

Shandong Kuaima Co., Ltd. has a 10-year history and an annual output of 50,000 tons. Now place an order. The first choice for cooperation. Good quality. 24-hour service. Complete specifications.

Copper strip

Get Quotation
VIEW MORE

copper wire

Get Quotation
VIEW MORE

Titanium wire

Get Quotation
VIEW MORE

Product Description

Product Description

Pure titanium is a silvery-white metal, which has many excellent properties. The density of titanium is 4.54g/cm3, 43% lighter than steel, and slightly heavier than the long-established light metal magnesium. Mechanical strength is similar to steel, twice as large as aluminum, five times larger than magnesium. Titanium high temperature resistance, melting point 1942K, higher than gold nearly 1000K, higher than steel nearly 500K.

Classification of titanium wire

Titanium wire is divided into: titanium wire, titanium alloy wire, pure titanium glasses wire, titanium straight wire, pure titanium wire, titanium welding wire, titanium hanging tool wire, titanium coil wire, titanium bright wire, medical titanium wire, titanium-nickel alloy wire.

Specification of titanium wire

Titanium wire size

A、Specification of titanium wire: φ0.8-φ6.0mm
B、Specifications of titanium wire for glasses: φ1.0-φ6.0mm special titanium wire
C、Specification of titanium wire:φ0.2-φ8.0mm special titanium wire for hanging tools

The main standards of titanium wire

GB/T,GJB,AWS,ASTM,AMS,JIS

Grades of titanium wire

TA0,TA1,TA2,TA3,TA4,TA5,TA6,TA7,TA9,TA10,TC1,TC2,TC3,TC4,TC6,TC11,GR1,GR2,GR3,GR5 Ti6AL4V ELI,Ti6AL7Nb,Ti13Nb13Zr,Ti1533

Status of titanium wire

Annealed state(M) Hot working state(R) Cold working state(Y)(annealed, super raw wave detection)

Surface of titanium wire

Pickled surface Bright surface

Titanium wire use

Military, medical, sporting goods, eyeglasses, earrings, headgear, plating pendant, welding wire and other industries.

Product Description

Product name

Titanium Wire 0.5mm  For Sale

Standard

ASTM B863 erc

Grade

Gr1, Gr2, Gr5(Ti-6Al-4V), Gr7, Gr9, Gr12, Gr23,Ti15333

Diameter

Φ0.5-7mm

Length

≤6000mm

Surface

Polished surface/peeling surface/machined surface/grinding surface

资质证书证书和客户

Titanium wire carburizing surface treatment

Titanium wire forms a stable carbide of higher hardness with carbon. The growth of the carburized layer between titanium and carbon is determined by the diffusion rate of titanium in the carburized layer.
The solubility of carbon in titanium is small, totaling 0.3% at 850X, and dropping to about 0.1% at 600C. Because of the small solubility of carbon in titanium, the only way to achieve surface hardening is basically through the deposition of the titanium carbide layer and its lower forsaking domain. Carburization must be carried out under the condition of oxygen removal, because the powder suitable for steel commonly carburized against the surface of carbon monoxide or carbon monoxide containing oxygen and the formation of the surface layer hardness reaches 2700MPa and 8500MPa, and the purpose. It is easy to peel off.
In contrast, a thin layer of titanium carbide may be formed when carburized in charcoal under deoxidized or decarburized conditions. The hardness of this layer is 32OUOMPa, which is in line with the hardness of titanium carbide. The depth of the carburized layer is approximately greater than the depth of the carburized layer when nitriding with nitrogen under the same conditions. Under oxygen-enriched conditions, oxygen absorption must be taken into account to affect the hardening depth. Only under very thin layer thickness conditions, in a vacuum or argon-methane atmosphere carburizing powder may form sufficient adhesion strength compared to this, the use of gas carburizing agent may form a particularly hard and well bonded titanium carbide hardened layer. At the same time the hardening spread is formed at temperatures between 950T: and 10201: at temperatures between 50fim and 50fim. As the layer thickness increases, the titanium carbide layer becomes more brittle and tends to flake off. In order to avoid carbon inclusions in the titanium carbide layer due to the decomposition of rane, gas carburization should be performed in an inert gas using a specified dose of additive with a volume fraction of approximately 2% rane. When propane additives are used and methane carburizing is utilized, a lower surface hardness is developed. The best wear resistance is achieved when propane is used for gas carburizing under the condition of bonding force up to UOkPa, although the measured thickness of the hardened layer is very thin. Hydrogen is absorbed under gas carburizing conditions, but it has to be removed again during vacuum annealing.

Our products are exported overseas, including Southeast Asia, Europe, North America, South America. In addition to overseas markets, we also operate a substantial domestic trading business, including supplying steel for various Chinese national infrastructure construction projects.
