Honed tubes

Honed tube & Skived & Roller burnished tubing are widely used for hydraulic cylinder and pneumatic cylinder manufacturing. So, it is also known as honed cylinder tubing. Kuaima is one of best quality China honed tube suppliers & manufacturers. Our honed tubing is ready to use for hydraulic cylinder applications without further ID processing.

Honed tube Manufacturing standards

Honed tubes can be manufactured & supplied with international standards as below:

  • DIN 2391 part 1: Seamless precision steel tubes – Dimensions
  • DIN 2391 part 2: Seamless precision steel tubes – Technical delivery conditions
  • EN10305-1: Steel tubes for precision applications –Technical delivery conditions Part 1: Seamless cold drawn tubes
  • ASTM A519 /A519M: Standard Specification for Seamless Carbon and Alloy Steel Mechanical Tubing
  • ASTM A513 /A513M: Standard Specification for Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing
  • JIS G3445: Carbon Steel Tubes for Machine Structural Purposes


Honed tube is usually a CDS (Cold drawn seamless) steel tube or DOM (Drawn Over Mandrel) steel tube with inside diameter honed or skived &roller burnished, so honed tubing is with extremely precise ID dimensions and smoothly ID surface.

Honed tubes are broadly utilized to produce and repair hydraulic cylinders and pneumatic cylinders. So in many fields, the honed tube is called cylinder tube also.

Honed tube usually is produced by two main manufacturing process, which are honing process or skiving & roller burnishing process. The mother tube we usually use “Suitable To Hone” Cold Drawn Seamless Tubes. The process of the honed pipe is determined upon the dimension, mold available and the requirement of the customer.

Chemical and Mechanical Properties of Honed cylinder tubes of material ST52 /ST52.3

Grade Chemistry % Yield Tensile Elongation Typical Hardness
min. Mpa min. Mpa % in 2″ section Min
ST52.3 Carbon 0.140 – 0.180 420 580 15 B-80
Si 0.150 – 0.300
Mn 1.200 – 1.400
P 0.020 max
S 0.010 max
