Carbon Steel Plate

Depending on the carbon content and strength, carbon steel sheets have different grades.
There are low, medium and high carbon steel plates. The higher the carbon content, the more durable and stronger the plate will be. There are further sub-categories depending on thickness and application as well as the formation process. Typically carbon steel plates are available in thicknesses from 0.4 mm to 80 mm, widths from 1000 mm to 45000 mm and lengths up to 18 meters. However, the lengths are customizable, which helps customers to put them into various applications, and they can also be used to manufacture cold rolled steel coils.

Carbon steel plate standards

Carbon steel plate includes almost all common standards for steel plates.
1. ASTM A36 plate - the most common carbon steel plate standard
2. ASTM A283 Grades A, B, C - also the most common material used in carbon construction
3. ASTM A516 - for boiler, vessel steel plates
4. ASTM A537 - For fusion welded pressure vessel and structural steel plates in heat treated carbon steel plate.
5. ASTM A573 - A carbon manganese silicon structural steel plate.
6. ASTM A572 - ASTM A572 plate mechanical strength is higher than A36. where the weight is lighter.
7. ASTM A737 - low alloy steel plate used for boilers, pressure vessels.
Thus carbon steel plate has wide coverage for different types of steel plates in different industries.

Carbon steel plate chemical composition

Grade C Si Mn P S Cu
ASTM A283 Grade A 0.14 0.15-0.40 0.9 0.035 0.04 0.2
ASTM A283 Grade B 0.17 0.15-0.40 0.9 0.035 0.04 0.2
ASTM A283 Grade C 0.24 0.15-0.40 0.9 0.035 0.04 0.2
ASTM A283 Grade D 0.27 0.15-0.40 0.9 0.035 0.04 0.2

Carbon steel plate physical properties

Grade Yield Strength (MPa) Ultimate Tensile Strength (MPa) Elongation at Break (%)
ASME SA283 GradeA 165 310-415 27
ASME SA283 GradeB 185 245-450 25
ASME SA283 GradeC 202 380-515 20
ASME SA283 GradeD 230 415-550 20

carbon steel plate specification

Product Name

carbon steel plate


AiSi, ASTM, bs, DIN, GB, JIS


Q235B/A/C/D Q355B/A/C/D 195 Q275B SPHC SPHD SPHE W1300 W800 W600A YS700MC Q420B Q450C Q500HX Q390B Q390C Q390D ZJ500


Hot Rolled

Surface Treatment



building materials

Special Use

High-strength Steel Plate







Processing Service

Decoiling, Cutting

Delivery Time

15-30 days

Hot sale product

carbon plate steel low carbon steel plate
carbon steel a36 plate low temp carbon steel plate
carbon steel diamond plate low temperature carbon steel plate
carbon steel plate astm 3/8 carbon steel plate
carbon steel plate for sale medium carbon steel plate
carbon steel plate suppliers mild carbon steel plate

lndustries Served

Every industry has its unique set of material specifications and needs. That’s why you can count on the exceptional experience and industry knowledge of the professionals at Kuaima Steel - Meeting the Exact Needs of Every Industry That Uses steel.

  • Machinery manufac- turing industry
  • Power Generation
  • Oil & Gas
  • Manufacturing
  • Construction
  • Ship Building
  • Automobile manufacturing
  • Pipe Fabrication

Our main export country

We are a well known worldwide exporter of Carbon steel plate, Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
