Alloy steel plate

Product catalogue

With the development of science and technology and industry, the material has put forward higher requirements, such as higher strength, resistance to high temperature, high pressure, low temperature, corrosion resistance, wear and other special physical and chemical properties of the requirements, carbon steel can not fully meet the requirements, so the emergence of alloy steel plate.

1060 alloy steel plate

4130 alloy steel plate

low alloy steel plate

Classification of alloy steel

According to the content of alloying elementsLow alloy steel (the total amount of alloying elements is less than 5%), medium alloy steel (the total amount of alloying elements is 5%-10%), high alloy steel (the total amount of alloying elements is higher than 10%).By alloying element compositionChromium steel (Cr-Fe-C), chromium-nickel steel (Cr-Ni-Fe-C), manganese steel (Mn-Fe-C), silicon-manganese steel (Si-Mn-Fe-C).According to the small specimen normalized or cast organizationPearlite steel, martensitic steel, ferrite steel, austenitic steel, lainitic steel.According to the use ofAlloy structural steel, alloy tool steel, special performance steel.

ASTM A514 H chemical composition

Grade	Standard	C	MN	P	S	SI	CR	MO	NI	V	B
alloy	ASTM A514 H	0.12 - 0.21	0.95 - 1.30	0.025	0.005	0.20 - 0.35	0.40 - 0.65	0.20 - 0.30	0.30 - 0.70	0.03 - 0.08	0.0005 - 0.005

ASTM A514 H Mechanical Properties

Grade	0.2% YS (ksi)	UTS (ksi)	ELONGATION IN 2" (MIN %)	REDUCTION OF AREA 1) (MIN %)
ASTM A514 H	100	110 - 130	16	35

Alloy steel plate specification

Standard	ASTM,AISI,DIN,EN,BS,SUS, JIS
Material	Q235, A36,SS400,Q345,St52,Gr60,Gr 70,A283,Gr A,Gr B,Gr C etc.
Thickness	0.3mm~800mm
Width	1m,1.2m,1.22m,1.5m,1.8m,2m,2.2m or as customer required
Length	2m,2.44m,3m,5.8m,6m or as customers required
Packing	Standard export seaworthy package,suit for all kinds of transport, or as required.
Delivery Time	According to the quantity you ordered or Upon negotiation
Price Term	EX-Working,FOB, C&F, CIF ,CNF or others
Application	steel plate are widely used in shipping building,engineer construction, mechanical manufacturing,the size of alloy steel sheet can be made according to clients required.
Sample	Free and available

Hot sale product

4130 alloy steel plate	high strength low alloy steel plate
4140 alloy steel plate	a514 alloy steel plate
4340 alloy steel plate	alloy 20 plate steel
alloy steel plate grades	alloy 20 steel plate
alloy steel plate supplier	alloy steel plate 4140
hot rolled alloy steel plate	alloy steel plate and sheet

lndustries Served

Every industry has its unique set of material specifications and needs. That’s why you can count on the exceptional experience and industry knowledge of the professionals at Kuaima Steel - Meeting the Exact Needs of Every Industry That Uses steel.

Machinery manufac- turing industry
Power Generation
Oil & Gas
Manufacturing
Construction
Ship Building
Automobile manufacturing
Pipe Fabrication

Our main export country

We are a well known worldwide exporter of Alloy steel plate , Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
