Shandong Kuaima Co., Ltd. has a 10-year history and an annual output of 50,000 tons. Now place an order. The first choice for cooperation. Good quality. 24-hour service. Complete specifications.
Aluminum plate, colored aluminum veneer, aluminum coil, aluminum foil, aluminum curtain wall, aluminum curtain wall reinforcement, embossed aluminum plate, alloy aluminum plate, patterned aluminum plate, non-slip aluminum plate and wide aluminum plate used for traffic signs and curtain wall decoration. Alloy grades 1050, 1060, 1100, 1200, 3003, 5052, 5082, 5182, 5083, 5754, 6061, 6063, 8011, etc.; alloy state 0.H24.H26.H22.HI8, etc.
Special specifications can be customized according to drawings and sizes!
Element | 3105 |
Silicon | 0.6 |
Iron | 0.7 |
Copper | 0.3 |
Manganese | 0.30-0.8 |
Magnesium | 0.20-0.8 |
Chromium | 0.2 |
Zinc | 0.4 |
Titanium | 0.1 |
Aluminum | balance |
Other Elements (each) | 0.05 |
Other Elements (total) | 0.15 |
Thickness (inch) | Yield Strength Min. (ksi) | Tensile Strength (ksi) | Elongation (%) | |
Min. | ||||
Min. | Max. | |||
0.017 – 0.019 | 15 | 19 | 26 | 1 |
0.020 – 0.031 | 15 | 19 | 26 | 1 |
0.032 – 0.050 | 15 | 19 | 26 | 2 |
0.051 – 0.080 | 15 | 19 | 26 | 3 |
Property | 3105 Data |
Density, lb/in3 | 0.0983 |
Modulus of Elasticity, psi | 10.0 x 106 |
Coefficient of Thermal Expansion, 68-212˚F, /˚F | 12.1 x 10-6 |
Thermal Conductivity, Btu/ft hr ˚F | 99 |
Specific Heat, Btu/lb ˚F | 0.214 |
Electrical Resistivity, Microohm-in | 1.504 |
Product Name | aluminium sheet manufacturers |
Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
Thickness | 0.1mm - 260mm |
Width | 500-2000mm |
Length | to clients’ requirement |
Coating | Polyester, Fluorocarbon, polyurethane and epoxy coating |
Surface | Mill finished, Coated, Embossed,Brushed, Polished, Mirror, Anodized,etc |
Gloss | Meet the customer requirement |
Material | Aluminum Alloy Metal |
Standard | GB/T3190-2008,GB/T3880-2006,ASTM B209,JIS H4000-2006,etc |
OEM service | Perforated, Cutting special size, Doing flatness, Surface treatment,etc |
Usage | Construction filed, Ships building industry, Decoration, Industry,Manufacture,Machinery and hardware fields, etc |
Delivery | In general, within 7-15 working days after receiving deposit or According to Final order quantity |
Packaging Details | Standard export package. |
Construction: Aluminum sheets are commonly used in construction, especially for roofing and siding applications. They are also used to construct gutters, flashings and downspouts. They are also popular for use as soffit panels.
Manufacturing: Aluminum sheets are commonly used to manufacture a variety of products, including appliances, automotive parts and packaging materials (such as cans and foil).
Other applications: Aluminum panels are also used in a variety of other applications, including signs and displays, license plate frames, and as a protective layer for wear-prone surfaces such as countertops.
