steel plate

Steel plates are flat sheets of steel that are poured with steel, cooled and pressed.
Steel plate is flat, rectangular and can be rolled directly or sheared from wide steel strip.
Steel plate is divided by thickness, thin steel plate <4mm (thinnest 0.2mm), medium thick steel plate 4~60mm, extra thick steel plate 60~115mm.
Steel plates are divided by rolling, into hot-rolled and cold-rolled.
The width of thin plate is 500~1500mm; the width of thick is 600~3000mm. Sheet by steel grade, there are ordinary steel, high-quality steel, alloy steel, spring steel, stainless steel, tool steel, heat-resistant steel, bearing steel, silicon steel and industrial pure iron sheet, etc.; by professional use, there are oil barrel with plate, enamel with plate, bulletproof with plate, etc.; by surface coating layer, there are galvanized sheet, tin-plated sheet, lead-plated sheet, plastic composite steel plate, etc.

1 2 3 4 5 6 7

Classification of steel plates

1.Classification by thickness: (1) thin plate, thickness not greater than 3mm (except electrical steel) (2) medium plate, thickness in 4-20mm (3) thick plate, thickness in 20-60mm (4) extra thick plate, thickness greater than 60mm
2.Classification by production method: (1) hot-rolled steel plate (2) cold-rolled steel plate
3.Classification by surface characteristics: (1) galvanized sheet (hot-dip galvanized sheet, electro galvanized sheet) (2) tin-plated sheet (3) composite steel sheet (4) color coated steel sheet
4.Classification by application: (1) Bridge steel plate (2) Boiler steel plate (3) Shipbuilding steel plate (4) Armor steel plate (5) Automobile steel plate (6) Roofing steel plate (7) Structural steel plate (8) Electrical steel plate (silicon steel sheet) (9) Spring steel plate (10) Heat-resistant steel plate (11) Alloy steel plate (12) Others

Chemical and Mechanical Properties of Stainless Steel Plate

Chemical and Mechanical Properties of Stainless Steel Plate:
Typical chemical requirements
304304L316/316L321
Carbon, Max %0.070.030.030.08
Manganese, Max %2222
Phosphorus, Max %0.0450.0450.0450.045
Sulphur, Max %0.030.030.030.03
Silicon Max0.750.750.750.75
Chromium range17.5-19.517.5-19.516-1817-19
Nickel range8.0-10.58-1210-149-12
Nitrogen Max0.10.10.10.1

Steel Plate Mechanical Properties

Mechanical Properties
304304L316/316L321
Tensile Min75 ksi70 ksi75 ksi75 ksi
Yield Min30 ksi25 ksi25 ksi30 ksi
Elongation Min40%40%40%40%
Hardness Max95 HRB95 HRB95 HRB95 HRB

Steel plate applications

1、Steel for structure
It is mainly used for the production of steel structural parts, bridges, ships and vehicles.
2、Weather resistant steel
Adding special elements (P, Cu, C, etc.), it has good corrosion resistance and atmospheric corrosion resistance, and is used for the production of containers and special vehicles, and also for building structures.
3、Steel for automobile structure
High strength steel plate with good stamping performance and welding performance, used for the production of FRAME, WHEEL, etc.
4、Hot rolled special steel
General mechanical structure with carbon steel, alloy steel, tool steel, after heat treatment engineering for the production of various mechanical parts.

lndustries Served

Every industry has its unique set of material specifications and needs. That’s why you can count on the exceptional experience and industry knowledge of the professionals at Kuaima Steel - Meeting the Exact Needs of Every Industry That Uses steel.

  • Machinery manufac- turing industry
  • Power Generation
  • Oil & Gas
  • Manufacturing
  • Construction
  • Ship Building
  • Automobile manufacturing
  • Pipe Fabrication

steel plate Outlet

We are a well known worldwide exporter of steel plate Qatar, Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
