Prepainted steel coil

Pre-painted steel is a bare metal substrate or corrosion resistant substrate that is painted on both sides by a continuous coil coating process to produce a uniform finish. In this process, the metal is unrolled, cleaned and chemically treated. Depending on product specifications, one or both sides can be primed and coated, oven cured and rewound.

Prepainted steel coil advantage

Pre-painted steel sheets consist of a steel core, metal coating, primer and topcoat.Galvanized and Galvalume (Aluzinc) is used as the base material, and after surface pretreatment, painting, baking and cooling, an organic protective film is formed on the steel base material. It has strong durability, corrosion resistance, decorative and forming properties.Pre-painted steel sheets can be used for advanced forming operations such as roll forming, bending and deep punching. Processing such as cutting, roll forming, bending, and folding can be performed. Pre-painted steel sheet is primarily used for roof and wall cladding, but it is often given a load-bearing function for wall, roof and floor structures as well.


Prepainted steel coil specification

Item

PPGI / PPGL color prepainted galvalume aluzinc galvanized steel sheets / coils / plates / strips

Material

SGCC SGCH SGC340 SGC400 SGC440 SGC490 SGC570

SGHC SGH340 SGH400 SGH440 SGH490 SGH540

DX51D DX52D DX53D DX54D DX55D DX56D DX57D

Standard

AiSi, ASTM, BS, DIN, GB, JIS

Technique

Cold rolled

Thickness

0.12 -- 1.5mm

Width

600/650/750/830/914/1000/1200/1219/1220/1250mm

Basic Coil

Hot-dipped galvanized / Alu-zinc Coils

Top side

5um + 13~20microns

Back side

5~8microns / 5+10microns

Color

RAL numbers or customers samples color

Zinc coating

20 -- 275G/M2

ID coil

508mm / 610mm

Coil weight

3 -- 8MT

Painting Type

PE, HDP, SMP, PVDF

Package

Properly packed for ocean freight:First: inside is kraft paper;
Second: water plastic film is in the middle ;
Third: outside GI steel sheet to be covered by steel strips with lock.

Application

General service, home appliances, Industry, Decoration, Construction, Car, Appliance of daily life, Roof etc.

MOQ

27 tons one container, for less quantity, to contact with us for details

Price terms

FOB, CFR, CIF

Payment terms

TT, L/C normally

Delivery time

10-20 days after the deposit or original L/C;

Prepainted steel coil applications

Construction industry
Household equipment
Automotive
Packaging
Industrial applications
Solar
