Stainless steel channel steel is a long strip of steel with a groove-shaped cross-section. Same as the I-beam, stainless steel channel steel is also divided into ordinary channel steel and light channel steel. The representation method of model and specification is also expressed in millimeters of waist height (h) × leg width (b) × waist thickness (d). Such as 120 × 53 × 5 channel steel, that is, waist height 120mm, round steel, need to add a, b, c, etc. on the right side of the model to distinguish.
Usually, the stainless steel channel steel is expressed in centimeters of the waist height, such as the above channel steel is called 12# channel steel. The specification range of channel steel is 5-40#. Including and marking requirements shall be implemented according to the provisions of GB2101-80.
Stainless steel channels are utilized in fabrication projects that are exposed to more corrosive conditions, such as acids, chemicals, petrochemicals, and fresh and salt water environments. Stainless hot rolled beams are also widely employed in architectural applications. Some of the primary advantages of stainless channel beams are as follows:
Strength-to-Weight benefits – The structural composition of stainless tube provides for a better strength-to-weight ratio than some other forms of metal.
Appearance – Stainless steel tube is bright and simple to clean, giving it a modern and appealing appearance.
Manufacturing – Because of the microstructure of 300 series stainless tube goods, they can be cut, welded, shaped, machined, and fabricated much like typical metals.
Corrosion resistance- The corrosion resistance of stainless steel makes them suitable for a variety of applications including use in process plants, water, acids, alkaline solutions, and chlorine.
Sanitation- Thanks to their ease of cleaning, stainless steel channels are ideal for use in high-hygiene environments like hospitals, kitchens, abattoirs, and food processing plants.
Resistance to fire and heat- Stainless steel resist scaling and maintain heat resistance.
| Chemical Composition(%) | ||||||||||||
| C | Si | Mn | P | S | Ni | Cr | Mo | Cu | N | Other | ||
| 1Cr17Mn6Mi5N | 201 | 0.15 | 1 | 5.5-5.7 | 0.06 | 0.03 | 3.3-3.5 | 16-18 | _ | _ | 0.05-0.25 | |
| 1Cr18Mn8Mi5N | 202 | 0.15 | 1 | 7.5-10 | 0.06 | 0.03 | 4.0-6.0 | 17-19 | _ | _ | 0.05-0.25 | |
| 1Cr18Mn8Mi5N | 301 | 0.15 | 1 | 2 | 0.07 | 0.03 | 6.0-8.0 | 16-18 | _ | _ | 0.1 | |
| 0Cr18Ni9 | 304 | 0.07 | 1 | 2 | 0.035 | 0.03 | 8.1-10.0 | 17-19 | _ | _ | _ | |
| 0Cr18Ni9 | 309S | 0.08 | 1 | 2 | 0.035 | 0.03 | 12.0-15.0 | 22-24 | _ | _ | _ | |
| 0Cr25Ni20 | 310S | 0.08 | 1 | 2 | 0.035 | 0.03 | 19.0-22.0 | 24-26 | _ | _ | _ | |
| 0Cr17Ni12Mo2 | 316 | 0.08 | 1 | 2 | 0.035 | 0.03 | 10.0-14.0 | 16-18.5 | 2.0-3.0 | _ | _ | |
| 00Cr17Ni14Mo2 | 316L | 0.08 | 1 | 2 | 0.035 | 0.03 | 12.0-15.0 | 16-18 | 2.0-3.0 | _ | _ | |
| 0Cr18Ni12Mo3Ti | 316Ti | 0.08 | 1 | 2 | 0.035 | 0.03 | 11.0-14.0 | 16-19 | 2.5-3.5 | _ | _ | Ti≥5C |
| 0Cr18Ni12Mo3Ti | 317L | 0.03 | 1 | 2 | 0.035 | 0.03 | 11.0-15.0 | 18-20 | 3.0-4.0 | _ | _ | |
| 1Cr18Ni9Ti | 321 | 0.12 | 1 | 2 | 0.035 | 0.03 | 8.0-11.0 | 17-19 | _ | _ | _ | Ti5C-0.70 |
| 1Cr12 | 430 | 0.12 | 1 | 2 | 0.035 | 0.03 | 0.6 | 16-18 | _ | _ | _ | |
| 00Cr20Ni25Mo4.5Cu | 904L | 0.02 | 1 | 2 | 0.035 | 0.03 | 23.0-28.0 | 19-23 | 4.0-5.0 | 1.0-2.0 | 0.14-0.20 | |
| 00Cr2Ni5Mo3N | 2205 | 0.03 | 1 | 2 | 0.035 | 0.02 | 4.5-6.5 | 21-23 | 2.5-3.5 | _ | _ |
item | value |
Standard | AiSi, ASTM, DIN, EN, GB, JIS |
Grade | 300 Series |
Shape | U Channel |
Perforated Or Not | Not Perforated |
Place of Origin | China |
Shandong | |
Brand Name | baowu |
Tolerance | ±1% |
Processing Service | Bending, Welding, Decoiling, Punching, Cutting |
Steel Grade | 301L, 301, 304N, 410, 316Ti, 316L, 420J1, 321, 410L |
Surface Finish | 2B |
Invoicing | by theoretical weight |
Delivery Time | 15-21 days |
Product name | Shape Stainless Steel Channel |
Keyword | 304 STAINLESS STEEL CHANNEL |
Technique | Cold Rolled Hot Rolled |
Payment term | 30%T/T Advance + 70% Balance |
Delivery Condition | FOB |
Material | 200 Series/300 Series/400series |
Surface Treatment | Heat Treatment |
MOQ | 500KG |
Grade of Material | 304L |
Application | Steel Structure Building |
