Copper wire has several important properties that make it a “natural” for electrical wiring. More than any other non-precious metal, it is the best conductor of electricity, packing more power into a given diameter of wire than any substitute material. Copper wire is also easier to bend. With copper wire, connections are easy and sure. And, because it has a high melting point, it can take surprisingly heavy overloads or current surges without damage or danger.
Copper wire has several important properties that make it a “natural” for electrical wiring. More than any other non-precious metal, it is the best conductor of electricity, packing more power into a given diameter of wire than any substitute material. Copper wire is also easier to bend. With copper wire, connections are easy and sure. And, because it has a high melting point, it can take surprisingly heavy overloads or current surges without damage or danger.
Type | Name | Section Area(mm2) | No. of Core | Application Site |
KVV | Copper Conductor,PVC Insulated and Sheathed Control Cable | 0.75 1.0 1.5 2.5 | 2-16 | Permanent installation indoors,in cable ditches or pipes |
4 6 | 2-14 | |||
10 | 2-10 | |||
KVVP | Copper Conductor,PVC Insulated and Sheathed,Braiding Shielded Control Cable | 0.75 1.0 1.5 2.5 | 2-61 | Permanent installation indoors,in cable ditches or pipes where shielding is required |
4 6 | 2-14 | |||
10 | 2-10 | |||
KVVP2 | Copper Conductor,PVC Insulated and Sheathed,Copper-tape Screened Control Cable | 0.75 1.0 1.5 2.5 | 4-10 | Permanent installation indoors,in cable ditches or pipes where shielding is required |
4 6 | 7-61 | |||
10 | 4-10 | |||
KVV22 | Copper Conductor,PVC Insulated and Sheathed,Steel tape Armored Control Cable | 0.75 1.0 1.5 2.5 | 7-61 | Permanent installation indoors,in cable ditches,Be able to withstand stronger external mechanical force |
4 6 | 4-14 | |||
10 | 4-14 | |||
KVVR | Copper Conductor,PVC Insulated and Sheathed,Flexible Control Cable | 0.5-2.5 | 4-61 | Installation indoors where flexibility and movability are required |
KVVRP | Copper Conductor,PVC Insulated and Sheathed,Braiding shielded Flexible Control Cable | 0.5 0.75 1.0 | 4-61 | Installation indoors where flexibility shielding and movability are required |
1.5 2.5 | 4-48 | |||
KYJV | Copper Conductor,XLPE Insulated and PVC Sheathed Control Cable | 0.75 1.0 1.5 2.5 | 2-16 | Permanent installation indoors,in cable ditches or pipes |
4 6 | 2-14 | |||
10 | 2-10 | |||
KYJVP | Copper Conductor,XLPE Insulated,Braiding Shielded,PVC Sheathed Control Cable | 0.75 1.0 1.5 2.5 | 2-61 | Permanent installation indoors,in cable ditches or pipes where shielding is required |
4 6 | 2-14 | |||
10 | 2-10 | |||
KYJV22 | Copper Conductor,XLPE Insulated,Steel-tape Armoured,PVC Sheathed Control Cable | 0.75 1.0 1.5 2.5 | 7-61 | Permanent installation indoors,in cable ditches,pipes or underground Be cable to with stand stronger external mechanical force |
4 6 | 4-14 | |||
10 | 4-10 | |||
KYJVP2 | Copper Conductor,XLPE Insulated,Copper tape Screened,PVC Sheathed Control Cable | 0.75 1.0 1.5 2.5 | 7-61 | Permanent installation indoors,in cable ditches or pipes where shielding is required |
4 6 | 4-14 | |||
10 | 4-10 | |||
KYJVR | Copper Conductor,XLPE Insulated,PVC Sheathed Flexible Control Cable | 0.5-2.5 | 4-61 | Installation indoors where flexibility and movability are required |
KYJVRP | Copper Conductor,XLPE Insulated,Braiding Shielded,PVC Sheathed Flexible Control Cable | 0.5 0.75 1.0 | 4-61 | |
1.5 2.5 | 4-48 | Installation indoors where flexibility shielding and movability are required |
Name | Chemical Composition (%): | |||||||||||
Copper Scrap | Cu: ≥ | Bi:≤ | Sb:≤ | As:≤ | Fe:≤ | Ni:≤ | Pb:≤ | Sn:≤ | S:≤ | O:≤ | Zn:≤ | P:≤ |
99.95 | 0.002 | 0.002 | 0.002 | 0.005 | 0.002 | 0.005 | 0.002 | 0.005 | 0.002 | 0.005 | 0.001 |
UL TYPE | Gauge | Construction | conductor outer diameter | insulation thickness | wire O.D | Max Cond. resistance(Ω/km ,20ºC | packing | |
(AWG) | (no/mm) | (mm) | (mm) | (mm) | FT/ROLL | METER/ROLL | ||
1569 | 30 | 1/0.254 | 0.25 | 0.4 | 1.05 | 361 | ||
7/0.1 | 0.3 | 0.4 | 1.1 | 381 | 2000 | 610 | ||
28 | 1/0.32 | 0.32 | 0.39 | 1.1 | 227 | |||
7/0.127 | 0.38 | 0.41 | 1.2 | 239 | ||||
7/0.127 OS-1 | 0.38 | 0.41 | 1.2 | 239 | ||||
26 | 1/0.404 | 0.4 | 0.43 | 1.25 | 143 | |||
7/0.16 | 0.48 | 0.41 | 1.3 | 150 | ||||
7/0.16 OS-1 | 0.48 | 0.41 | 1.3 | 150 | ||||
24 | 1/0.511 | 0.51 | 0.42 | 1.35 | 89.3 | |||
11/0.16 | 0.61 | 0.4 | 1.4 | 94.2 | ||||
7/0.2 OS-1 | 0.6 | 0.41 | 1.4 | 94.2 | ||||
22 | 1/0.643 | 0.64 | 0.43 | 1.5 | 56.4 | |||
17/0.16 | 0.76 | 0.42 | 1.6 | 59.4 | ||||
7/0.254 OS-1 | 0.76 | 0.42 | 1.6 | 59.4 | ||||
20 | 1/0.813 | 0.81 | 0.42 | 1.65 | 35.2 | |||
26/0.16 | 0.94 | 0.43 | 1.8 | 36.7 | ||||
7/0.32 OS-1 | 0.96 | 0.42 | 1.8 | 36.7 | ||||
18 | 1/1.024 | 1.02 | 0.41 | 1.85 | 22.2 | 1000 | 305 | |
41/0.16 | 1.18 | 0.46 | 2.1 | 23.2 | ||||
7/0.404 OS-1 | 1.2 | 0.45 | 2.1 | 23.2 | ||||
16 | 1/1.129 | 1.29 | 0.46 | 2.2 | 14 | |||
26/0.254 | 1.49 | 0.46 | 2.4 | 14.6 | ||||
14 | 1/1.6 | 1.6 | 0.45 | 2.5 | 8.78 | |||
41/0.254 | 1.88 | 0.41 | 2.7 | 8.96 | ||||
12 | 65/0.254 | 2.36 | 0.42 | 3.2 | 5.64 | |||
10 | 7/15/0.254 | 3.42 | 0.44 | 5.05 | 3.54 |
