409L stainless steel coil features

1、Ferrite stainless steel with low C, N and Ti additions. 2、Nickel-free, low cost and stable price. 3、High thermal conductivity, low coefficient of thermal expansion, good formability and bendability. 4、Good corrosion resistance and high temperature strength. 5、Low C plus Ti, no need for post-weld heat treatment.

Product Details

409L stainless steel coil description

Grade 409L (UNS S40900, EN 1.4512) is a stable version of 409 consisting of the appropriate chromium, low carbon and nitrogen compositions and titanium additives, all of which apply to Grade 409L for a wide range of properties, corrosion resistance, weldability and formability. Due to its low chromium content, grade 409L is a low-cost alternative to corrosion-resistant stainless steels.
Grade 409L offers a good combination of heat and corrosion resistance and is well suited for non-corrosive or mildly corrosive environments or applications. Excellent high temperature oxidation resistance and good weldability for automotive exhaust or petroleum equipment.

Stainless Steel Coil specification

Stainless Steel Coil/Sheet/Plate Information



Technique


Surface Finish


Grade Series


Thickness(mm)

Width(mm)

Main Dimension

20-850

1000

1219

1240

1250

1500

Hot Rolled

No.1 / 2E

201/304/316L

2.2-12.0







Cold Rolled


2B

201/304/316L

0.25-3.0

410S/430

410S/430

0.25-3.0


No.4 /Hairline

Mirror / Linen

SB

201/304/316L

0.22-3.0

410S/430

410S/430

0.25-3.0


BA

201/304

0.2--1.8

410S/430

410S/430

0.25-3.0



2BA

304/410S/430

0.25-2.0



If you need, we can customize the size according to your requirements



409L stainless steel coil chemical composition

CMnSiPSCrNiTi
0.081.01.00.0450.04510.5-11.750.50.48 0.75

409L stainless steel coil mechanical property

Tensile Strength MPa (min)Yield Strength 0.2% MPa(min)Elongation %Hardness (Brinell) MAXHardness (Rockwell B) MAX
