301 stainless steel coil is a type of hardenable austenitic stainless steel with high strength, moderate corrosion resistance and good formability.
· Good resistance in applications involving external exposure to mildly corrosive conditions at ambient temperatures.
· Resists outdoor, industrial, marine, and mild chemical environments
· susceptible to carbide precipitation during welding, which restricts its use in some applications
· Similar to resistance of Stainless Steel grade 304
· Can be exposed continuously without appreciable scaling to a max of 1600°F(871°C).
· Maximum exposure temperature is about 1450°F (788°C), for intermittent exposure
· Has an oxidation weight gain of 10mg/cm 2 in 1,000 hours, in temperatures over 1600°F (871°C).
· Solution Treatment (Annealing) – Heat to 1010-1120°C and cool rapidly.
· Use low side of range for intermediate annealing.
· This grade cannot be hardened by thermal treatment.
· hardens at high rate, creating a very high strength from cold rolling and from roll forming.
· more difficult to work than other austenitic stainless steels, due to its high work hardening rate..
· strain-hardened austenitite steel undergoes partial transformation into martensitite steel during this process.
· severe cold deformation can still occur, due to residual ductility.
· Grade 301 becomes strongly magnetic when cold rolled.
· must be annealed for maximum corrosion resistance
· more difficult to work than other austenitic stainless steels, due to its high work hardening rate..
· must be annealed for maximum corrosion resistance
· Welding and post weld annealing will both remove high strength induced by prior cold rolling.
· Spot welding is commonly used to assemble cold rolled 301 components..
· material will lose temper in the heat affected weld zone.
Stainless Steel Coil/Sheet/Plate Information | |||||||||
| Surface Finish | Grade Series | Thickness(mm) | Width(mm) | |||||
Main Dimension | |||||||||
20-850 | 1000 | 1219 | 1240 | 1250 | 1500 | ||||
Hot Rolled | No.1 / 2E | 201/304/316L | 2.2-12.0 | √ | √ | √ | √ | √ | |
Cold Rolled | 2B | 201/304/316L | 0.25-3.0 | √ | √ | √ | √ | √ | √ |
410S/430 | 410S/430 | 0.25-3.0 | √ | √ | √ | √ | |||
No.4 /Hairline Mirror / Linen SB | 201/304/316L | 0.22-3.0 | √ | √ | √ | √ | √ | √ | |
410S/430 | 410S/430 | 0.25-3.0 | √ | √ | √ | √ | √ | ||
BA | 201/304 | 0.2--1.8 | √ | √ | √ | √ | √ | √ | |
410S/430 | 410S/430 | 0.25-3.0 | √ | √ | √ | ||||
2BA | 304/410S/430 | 0.25-2.0 | √ | √ | √ | √ | |||
If you need, we can customize the size according to your requirements | |||||||||
Chemical composition and mechanical properties of stainless steel coils | |||||||||
Grade | Chemical Composition (%) | Mechanical Performance | |||||||
C | Si | Mn | P | S | Ni | Cr | Mo | Hardness | |
201 | ≤0.15 | ≤1.00 | 5.5/7.5 | ≤0.060 | ≤0.03 | 3.5/5.5 | 16.0/18.0 | - | HB≤241,HRB≤100, HV≤240 |
304 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 8.0/11.0 | 18.0/20.0 | - | HB≤187,HRB≤90,HV≤200 |
316 | ≤0.08 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.0/14.0 | 16.0/18.0 | 2.0/3.0 | HB≤187,HRB≤90,HV≤200 |
316L | ≤0.03 | ≤1.00 | ≤2.00 | ≤0.045 | ≤0.03 | 10.0/14.0 | 16.0/18.0 | 2.0/3.0 | HB≤187,HRB≤90,HV≤200 |
410 | ≤0.15 | ≤1.00 | ≤1.25 | ≤0.060 | ≤0.03 | ≤0.060 | 11.5/13.5 | - | HB≤183, HRB≤88 HV≤200 |
430 | ≤0.12 | ≤1.00 | ≤1.25 | ≤0.040 | ≤0.03 | - | 16.0/18.0 | - | HB≤183, HRB≤88 HV≤200 |
· aircraft structural parts
· trailer bodies
· utensils
· architectural and automotive rim
· roof drainage products
· conveyor belts
· variety of industrial applications.
