310S stainless steel coil

Alloy 310 is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weldability. It is typically used for elevated temperature applications as its high chromium and nickel content provide solid corrosion resistance, excellent resistance to oxidation, and superior strength in temperatures up to 2100°F. Due to its high chromium and nickel content, it is superior to 304 or 309 stainless in most environments.

Product Details

310S stainless steel coil

Alloy 310 is an austenitic stainless steel that combines excellent high temperature properties with good ductility and weldability. It is typically used for elevated temperature applications as its high chromium and nickel content provide solid corrosion resistance, excellent resistance to oxidation, and superior strength in temperatures up to 2100°F. Due to its high chromium and nickel content, it is superior to 304 or 309 stainless in most environments.

VALUE ADDED SERVICES:

· Need a special length?

o We can custom level 3/8″ thick x 72″ x 186″ from our plate line to reduce scrap

· Polish plate inventory available

o We supply #4, #6, and #8 mirror finish

o Special polishes available

· Plate processing

· Dynamic water jet cutting

· Plate shearing

· Saw cutting

· Plasma cutting and high quality plasma cutting

· Machine cut rings and discs

Penn Stainless Alloy 310S Plate and Processed Flat Bar provides superior resistance to corrosion and heat exposure, in even the most demanding environments.

CORROSION RESISTANCE:

· Provides excellent corrosion resistance

· High chromium content allows for good aqueous corrosion resistance

· Excellent resistance at normal temperatures and also has good resistance to oxidizing and carburizing atmospheres

HEAT RESISTANCE:

· Good resistance to oxidation in intermittent service in air at temperatures up to 1040°C and 1150°C in continuous service.

· Good resistance to thermal fatigue and cyclic heating.

· Widely used where sulphur dioxide gas is encountered at elevated temperatures.

· Continuous use in 425-860°C range not recommended due to carbide precipitation, if subsequent aqueous corrosion resistance is needed

· Generally used at temperatures starting from about 800 or 900°C – above the temperatures at which 304H and 321 are effective.

FABRICATION:

· Commonly used in the heat treatment and process industries due to high temperature and corrosive environments

· Often fabricated into complex structures

· Roller-forms, stamps and draws readily

· Because 310 work hardens, severe forming operations should be followed by an anneal

WELDABILITY:

· Austenitic stainless steel is generally considered to be weldable

· Generally considered to have weldability equivalent to 304 and 304L

· Special consideration is needed to compensate for a higher coefficient of thermal expansion to avoid warping and distortion


Product Introduction of Stainless Steel Coil

Stainless Steel Coil/Sheet/Plate Information



Technique


Surface Finish


Grade Series


Thickness(mm)

Width(mm)

Main Dimension

20-850

1000

1219

1240

1250

1500

Hot Rolled

No.1 / 2E

201/304/316L

2.2-12.0







Cold Rolled


2B

201/304/316L

0.25-3.0

410S/430

410S/430

0.25-3.0


No.4 /Hairline

Mirror / Linen

SB

201/304/316L

0.22-3.0

410S/430

410S/430

0.25-3.0


BA

201/304

0.2--1.8

410S/430

410S/430

0.25-3.0



2BA

304/410S/430

0.25-2.0



If you need, we can customize the size according to your requirements


chemical composition of 310S stainless steel coil

Grade C Mn Si P S Cr Mo Ni N

310S stainless steel coil

minimum 24 19
maximum 0.25 2 1.5 0.045 0.03 26 22

mechanical property of 310S stainless steel coil

Yield Strength Ultimate Tensile Elongation Hardness
0.2% Offset Strength in 2 in.
psi (min.) (MPa) psi (min.) (MPa) % (min.) (max.)
35,000 245 80,000 550 45 217 Brinell

APPLICATIONS of 310S stainless steel coil

The higher alloyed stainless steels generally have excellent strength at elevated temperatures along with outstanding resistance to creep deformation and environmental attack. Therefore, Alloy 310 is used widely in industries such as heat treatment and chemical processing. Some examples include:

· Furnace Parts

· Oil Burner Parts

· Heat Exchangers

· Welding Filler Wire and Electrodes

· Annealing Covers

· Combustion Tubes

· Fire Box Sheets
