Product Description

Aluminum Coil

We have rich experience in foreign trade and supply high quality steel for a long time. Complete specification of aluminum, advantageous price and quality assurance. Quality certificate. China steel exporter. Factory direct sales. High quality steel supplier.

PRODUCT DESCRIPTION

Aluminum Coil

Aluminum  Coil

Aluminum strip is made of pure aluminum or aluminum alloy cast and rolled aluminum coils, hot rolled aluminum coils, rolled into thin aluminum coils of different thickness and width by cold rolling machine, and then longitudinally cut into aluminum strips of different widths by slitting machine.

Product Classification

The common alloy grades of aluminum strip are 1050, 1060, 1070, 1100, 3003, 3004, 5005, 5052, 8011, etc. The common states are O state and H state. The common states are O and H. O means soft state, H means hard state, and O and H can be followed by numbers to indicate the degree of softness and hardness, and the degree of annealing.

The specific uses of aluminum strip are: aluminum strip for transformer (transformer aluminum foil), aluminum strip for high frequency welding hollow aluminum strip, aluminum strip for fin radiator, aluminum strip for cable, aluminum strip for stamping, aluminum strip for aluminum edge strip, etc.

The categories of aluminum alloy strips are: pure aluminum strips, transformer aluminum strips, super hard aluminum strips, full soft aluminum strips, semi-hard aluminum strips, and rust-proof aluminum strips.

Processing Technology:

Aluminum strip is a deep-processed aluminum product formed by slitting and processing aluminum coils. It is an important raw material in the industry.

Depending on the alloying elements contained in the strip, aluminum strip is divided into 8 series, just like aluminum sheet. However, the commonly used series are 1000, 3000, 5000 and 8000 series.

According to the annealing state of aluminum strip, it can be divided into full soft (o-state) semi-hard (H24) and full hard (h18). The most commonly used should belong to the full soft series, because the O state is easier to stretch and bend.

The main processing equipment for aluminum strip is the slitting machine, which can be divided into the required length and width according to the needs. Of course, the equipment for slitting processing is universal and can also be used for processing copper coils, and the processed product is called copper strip.

The international raw material for electronic products is no longer purely dependent on copper tape, because the electrical conductivity of aluminum is just lower than copper, so aluminum tape instead of copper tape is becoming a popular trend in the international.


PRODUCT DESCRIPTION

Product NameAluminum Coil
Alloy/Grade1000/3000/4000/5000/6000/7000 Series
TemperO-H112,T3-T8,T351-T851
Thickness0.1mm-6.5mm or as your requirement
WidthAs per your requirements
LengthAs per your requirements
ApplicationIndustry/Decoration/Building/Packing/Pressing,etc
Surface treatmentMill Finish/Coated/Power Coated/Anodized/Polished mirror/Emobossed
ToleranceAs per your requirements
Delivery Time7-30 days after order confirmation
MOQ5Ton
Loading PortShanghai port
Coil IDAs your requirements
Price TermsFOB CIF CFR EXW
Payment TermsLess than USD$1000000:TT with 30% deposit,and balance against the copy of B/L
NaNOver USD$1000000:TT with 10% deposit,the balance 90% LC at sight
StandardsASTM-B209,EN573-1,GB/T3880.1-2006

Product Show

1

Certificates

2

Product Applications

Product Applications

Aluminum strip has many applications, such as: aluminum composite tubes, cables, fiber optic cables, transformers, heaters, louvers, etc.

  • 1060 is typically used for chemical equipment where high corrosion resistance and formability are required, but not high strength.
  • 1100 Used for processing parts that require good formability and high corrosion resistance but do not require high strength, such as chemical products, food industry devices and storage containers, sheet machined parts, deep drawn or spun concave vessels, welded parts, heat exchangers, printing plates, nameplates, reflective appliances
  • 3004 Sheets, thick plates, drawn tubes. Extruded tubes as long as they are used for all-aluminum can bodies, parts requiring a higher alloy than 3003, chemical production and storage devices, thin sheet machined parts, construction baffles, cable ducts, sewers, various lamp parts.
  • 3003 sheet. Strip. Foil. Thick plates, drawn tubes. Extruded tubes. Profiles. Bar. Wire. Cold worked bar, cold worked wire, rivet wire, forgings, foil, heat sink material is mainly used for processing parts that require good forming properties, high corrosion resistance, or good weldability, or workpieces that require both these properties and higher strength than 1*** system alloys, such as tanks and tanks for transporting liquids, pressure tanks, storage devices, heat exchangers, chemical equipment, aircraft fuel tanks, oil ducts, reflectors kitchen equipment, washing machine cylinders, rivets, welding wire.
  • 5052 This alloy has good forming and processing properties, corrosion resistance, candleability, fatigue strength and medium static strength, used in the manufacture of aircraft fuel tanks, fuel pipes, and sheet metal parts of transportation vehicles, ships, instruments, street light brackets and rivets, hardware products, etc.
