Titanium manufacturers and suppliers: titanium rods, plates, sheets and tubes. Contact us now. Titanium. In stock - fast delivery - certified materials - quality products.
Titanium tubes are the ninth most abundant element in the earth’s crust and the seventh most abundant metal. Its low density, slightly over half that of steel, and its high strength combination is the reason for the metals growing preference in both military and commercial aircraft. The alloying of titanium tubing with elements such as aluminum and vanadium increase the strength of titanium while at the same time retains its weight advantage over steel.
| Name | ASTM B 338 gr2 titanium tube ASTM B337 titanium pipe |
|---|---|
| Standard | ASTM B337, ASTM B338, |
| Grade | Gr1, Gr2, Gr9, Gr16 |
| Dimension | OD*Thk*L (10-114)*(0.4-10)*(100-15000)mm |
| Manufacturing method | Cold rolled |
| Condition | Annealed(M) |
| Features | Light weight, excellent corrosion resistivity, strongly heat-resistance, high strength. |
| Inspection | Ultrasonic testing, Hydrostatic testing, Flattening testing, visual surface inspection, Dimensional inspection, tensile properties inspection and Chemical elements analysis. |
| Grades | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade 2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade 5 | 90 min | 0.1 max | 0.4 max | 0.015 max | 0.05 max | 0.20 max | 5.5-6.75max | 3.5-4.5 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20% |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14% |
We are happy to answer any questions you have regarding our product lines and services. Please tell us a little more about yourself and we will have someone contact you as soon as possible.
Speak to a Steel Expert
Behind the growth and success of Kuaima Iron & Steel is the hard work and dedication in the steel industry for many years to meet the needs of customers in a timely manner. Advanced technology, standard products, certified quality standards and the best customer service have led me to years of hard work and dedication in the steel industry and to meet customer needs on time. Advanced technology, standard products, certified quality standards and the best customer service make Kuaima Steel a real leader in the global market
