Aircraft quality 4130 alloy steel is a medium carbon, low alloy steel containing 0.15/0.25% molybdenum and 0.80/1.10% chromium as strengthening agents. This type of steel is also commonly referred to as a chromoly steel, or chrome moly steel. Due to its relatively low carbon content of 0.28/0.33%. These 4130 steel properties offer exceptional weldability. With the proper heat treatment it is also readily machined. Annealing 4130 (E4130) alloy steel offers excellent ductility. 4130 steel can also be normalized or otherwise heat treated. Steel 4130 (E4130) has an excellent strength to weight ratio and is considerably stronger and harder than other standard grades of steel. Chromoly steels are especially useful in their ability to retain their bulk properties while allowing for significant hardness to be attained.
It is an exceptional welding steel, being weldable in all commercial methods, and is readily machined in its normalized/tempered condition. 4130 steel is easily cold worked, hot worked, and forged, but cannot be aged. It has excellent ductility when annealed and is a through-hardening alloy.
4130 steel is an alloy made up of chromium and molybdenum. It has a higher strength-to-weight ratio than mild steel, making it ideal for projects where weight is a significant factor, such as automotive parts or aircraft components. It also has superior corrosion resistance and can tolerate very high temperatures without losing its shape or integrity. However, because it’s much harder than mild steel, it can be difficult to cut or form into shapes without special tools and equipment.
| C | Mn | P | S | Si | Cr | Mo | |
|---|---|---|---|---|---|---|---|
| Min | 0.28 | 0.40 | – | – | 0.15 | 0.80 | 0.15 |
| Max | 0.33 | 0.60 | 0.025 | 0.025 | 0.35 | 1.10 | 0.25 |
| 0.2% Proof Stress | Tensile Strength | Elongation | |
|---|---|---|---|
| MPA | MPA | % | |
| Annealed | 586 | ||
| Normalised | |||
| Up to 0.062" | 517 | 655 | 8 |
| 0.062" – 0.125" | 517 | 655 | 10 |
| 0.125" – 0.187" | 517 | 655 | 12 |
| 0.187" – 0.249" | 482 | 620 | 15 |
| 0.249" – 0.749" | 482 | 620 | 16 |
| 0.749" – 1.5" | 482 | 620 | 18 |
Specification | |
GB: Q195, Q215, Q235A, Q235B, Q235C, Q235D, Q255A, 255B, Q275, Q295A, Q295B,Q345B,Q345C,Q345D,Q345E,Q390A,Q390B,Q390C,Q390D,Q390E,Q420,Q420B,Q420C,Q420DQ420E,Q460D, Q460E, Q500D, Q500E, Q550D, Q550E, Q620D,Q620E,Q690D,Q690E EN: S185, S235JR, S275JR, S355JR, S420NL, S460NL S500Q, S550Q, S620Q, S690Q ASTM: Grade B, Grade C, Grade D, A36, Grade 36, Grade 40, Grade 42, Grade 50, Grade 55, Grade 60, Grade 65, Grade 80 JIS: SS330, SPHC, SS400, SPFC, SPHD, SPHE | |
Standard | GB/T709-2006, ASTM A36, JIS G4051, |
Thickness | 0.15mm-300mm |
Width | 500-2250mm |
Length | 1000mm-12000mm or according to customer's special request |
Tolerance | Thickness: +/-0.02mm, Width:+/-2mm |
MOQ | 2 Tons |
1.Automobile, Bridges, Buildings. | |
Package | Bundle with steel strip,Container shipping |
Capacity | 200000 tons /month |
Mill MTC | can be supplied before shipment |
Inspection | The Third Party inspection can be accepted,SGS,BV |
We are happy to answer any questions you have regarding our product lines and services. Please tell us a little more about yourself and we will have someone contact you as soon as possible.
Speak to a Steel Expert
Behind the growth and success ofuaima Steel is years of hard work and dedication in the steel industry and meeting customers' needs on time. Advanced technology, standard products, certified quality standards and the best customer service make l is years of hard work and dedication in the steel industry and meeting customers' needs on time. Advanced technology, standard products, certified quality standards and the best customer service make Kuaima Steel a true leader in zhe global marker
quality & experience
Technology & Innovation
Team & Quality
Service & Support
| 4340 4130 alloy steel plate | 4 x 8 plate steel alloy 354 |
| 4340 steel alloy plate | 4140 alloy steel plate suppliers |
| 520m40 alloy steel plate | 4140 hr alloy steel plate |
| 8620 alloy steel plate | 41cr4 alloy steel plate |
| a514 alloy steel plate | 42cd4 alloy steel plate |
| alloy 20 plate steel | 42crmo4 alloy steel plate |
Every industry has its unique set of material specifications and needs. That’s why you can count on the exceptional experience and industry knowledge of the professionals at Kuaima Steel - Meeting the Exact Needs of Every Industry That Uses steel.
We are a well known worldwide exporter of Alloy steel plate , Ireland, Portugal, Gambia, Thailand, Ukraine, United Kingdom, Netherlands, South Africa, Spain, Turkey, Italy, Libya, Romania, Puerto Rico, Azerbaijan, United Arab Emirates, Pakistan, Philippines, Ghana, Slovakia, Germany, Saudi Arabia, Afghanistan, China, Bolivia, Switzerland, Bangladesh, Taiwan, Oman, Egypt, Greece, Norway, Singapore, Bulgaria, Estonia, Belgium, Yemen, Hong Kong, Ecuador, Sri Lanka, Nepal, Belarus, Finland, Gabon, Iran, Canada, Argentina, Lebanon.
