China professional enameled wire manufacturer order now at low price! High quality copper or aluminum enameled wire factory. Professional factory. transformer wire. Highly mature copper strip manufacturer, fast delivery and standard export packaging. Manufacture a wide range of copper products with high quality and full service, please contact us.
Copper wire has several important properties that make it a “natural” for electrical wiring. More than any other non-precious metal, it is the best conductor of electricity, packing more power into a given diameter of wire than any substitute material. Copper wire is also easier to bend. With copper wire, connections are easy and sure. And, because it has a high melting point, it can take surprisingly heavy overloads or current surges without damage or danger.
Item | Value |
Type | Brass Wire |
Application | Conductive |
Grade | Brass,Copper |
Cu (Min) | ≥65% |
Alloy Or Not | Is Alloy |
Ultimate Strength (≥ MPa) | 315 |
Place of Origin | China |
Processing Service | Bending, Decoiling, Welding, Punching, Cutting |
Place of Origin | Hebei, China, hebei |
Model Number | rh, rh |
Application | Cable conductor |
Conductor Type | Copper |
Cu(%) | 99.99 |
Type | bare |
Conductor Material | Copper |
Shape | wire |
Size | Customized |
Color | copper |
| CDA Alloy No. | C10100 | C10200 | C11000 | C15000 | C17200 | C26000 | C51000 |
| Alloy Name | Certified | OFHC | ETP | Zirconium | Beryllium | Cartridge | Phosphor |
| OFHC | Copper | Copper | Copper | Copper | Brass | Bronze | |
| Copper | |||||||
| Chemical Composition (%) | 99.99 Cu | 99.95 Cu | 99.90 Cu | 98.95 Cu | 98.1 Cu | 70 Cu | 94.8 Cu |
| Min. | Min. | Min. | .15 Zr | 1.9 Be | 30 Zn | 5.0 Sn | |
| .04 O | .2 P | ||||||
| Density (lbs./in.³) | 0.323 | 0.323 | 0.323 | 0.321 | 0.298 | 0.308 | 0.32 |
| Electrical Conductivity (% IACS @ 68°F ) | 101 | 102 | 100 | 93 | 22 | 28 | 15 |
| Resistivity (Ω/circ. mil/ft) | 10.3 | 10.3 | 10.3 | 11.2 | 46.2 | 37 | 69.1 |
| Approximate Melting Point (° F ) | 1981 | 1981 | 1981 | 1796 | 1590 | 1680 | 1750 |
| Tensile Strength Hard Temper (kpsi) | 55 | 55 | 55 | 64 | 152 | 109 | 110 |
| Tensile Strength Soft Temper (kpsi) | 34 | 34 | 34 | 30 | 68 | 52 | 51 |
| Yield Strength Hard Temper (kpsi) | 50 | 50 | 50 | 62 | 125 | 68 | 85 |
| Yeild Strength Soft Temper (kpsi) | 11 | 11 | 12 | 13 | 28 | 21 | 21 |
| Elongation Hard Temper (%) | 6 | 6 | 5 | 1.5 | 1 | 5 | 5 |
| Elongation Soft Temper (%) | 36 | 36 | 36 | 30 | 42 | 30 | 49 |
We are happy to answer any questions you have regarding our product lines and services. Please tell us a little more about yourself and we will have someone contact you as soon as possible.
Speak to a Steel Expert
Behind the growth and success ofuaima Steel is years of hard work and dedication in the steel industry and meeting customers' needs on time. Advanced technology, standard products, certified quality standards and the best customer service make l is years of hard work and dedication in the steel industry and meeting customers' needs on time. Advanced technology, standard products, certified quality standards and the best customer service make Kuaima Steel a true leader in zhe global marker
quality & experience
Technology & Innovation
Team & Quality
Service & Support
| 10 gauge copper coil wire | 14g copper coil wire |
| 11 gauge copper coil wire | 16 gauge copper coil wire |
| 12 gauge copper coil wire | 17 gauge copper coil wire |
| 4 gauge copper coil wire | 18 gauge copper coil wire |
| 6 gauge copper coil wire | 19 gauge copper coil wire |
| 8 gauge copper coil wire | 20 gauge copper coil wire |
Every industry has its unique set of material specifications and needs. That’s why you can count on the exceptional experience and industry knowledge of the professionals at Kuaima Steel - Meeting the Exact Needs of Every Industry That Uses steel.
