317stainless steel coil application

1、 Flue-gas desulfurization systems 2、 Chemical process vessels 3、Petrochemical 4、 Pulp and Paper 5、 Condensers in power generation

email enquire now

Product Details

317stainless steel coil characters

1、CORROSION PROPERTIES:317L has excellent corrosion resistance in a wide range of chemicals, especially in acidic chloride environments such as those encountered in pulp and paper mills. Increased levels of chromium, nickel and molybdenum compared to 316L stainless steel improve resistance to chloride pitting and general corrosion. Resistance increases with molybdenum alloy content. 317L is resistant to sulfuric acid concentrations up to 5 percent at temperatures as high as 120°F (49°C). At temperatures under 100°F (38°C) this alloy has excellent resistance to solutions of higher concentration. However, service tests are recommended to account for the affects of specific operating conditions that may affect corrosion behavior. In processes where condensation of sulfur-bearing gases occurs, 317L is much more resistant to attack at the point of condensation than conventional alloy 316. The acid concentration has a marked influence on the rate of attack in such environments and should be carefully determined by service tests.

2、WELDING:317L is readily welded by a full range of conventional welding procedures (except oxyacetylene). AWS E317L/ER317L filler metal or austenitic, low carbon filler metals with molybdenum content higher than that of 317L, or a nickel-base filler metal with sufficient chromium and molybdenum content to exceed the corrosion resistance of 317L should be used to weld 317L steel.

Stainless Steel Coil specification

Stainless Steel Coil/Sheet/Plate Information
Technique	Surface Finish	Grade Series	Thickness(mm)	Width(mm)
				Main Dimension
				20-850	1000	1219	1240	1250	1500
Hot Rolled	No.1 / 2E	201/304/316L	2.2-12.0	√	√	√	√		√
Cold Rolled	2B	201/304/316L	0.25-3.0	√	√	√	√	√	√
	2B	410S/430	410S/430	0.25-3.0	√	√	√		√
	No.4 /Hairline Mirror / Linen SB	201/304/316L	0.22-3.0	√	√	√	√	√	√
	No.4 /Hairline Mirror / Linen SB	410S/430	410S/430	0.25-3.0	√	√	√	√	√
	BA	201/304	0.2--1.8	√	√	√	√	√	√
	BA	410S/430	410S/430	0.25-3.0	√	√	√
	2BA	304/410S/430	0.25-2.0	√	√	√	√
If you need, we can customize the size according to your requirements

Chemical composition and mechanical properties of stainless steel coils
Grade	Chemical Composition (%)								Mechanical Performance
Grade	C	Si	Mn	P	S	Ni	Cr	Mo	Hardness
201	≤0.15	≤1.00	5.5/7.5	≤0.060	≤0.03	3.5/5.5	16.0/18.0	-	HB≤241,HRB≤100, HV≤240
304	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	8.0/11.0	18.0/20.0	-	HB≤187,HRB≤90,HV≤200
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	10.0/14.0	16.0/18.0	2.0/3.0	HB≤187,HRB≤90,HV≤200
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	10.0/14.0	16.0/18.0	2.0/3.0	HB≤187,HRB≤90,HV≤200
410	≤0.15	≤1.00	≤1.25	≤0.060	≤0.03	≤0.060	11.5/13.5	-	HB≤183, HRB≤88 HV≤200
430	≤0.12	≤1.00	≤1.25	≤0.040	≤0.03	-	16.0/18.0	-	HB≤183, HRB≤88 HV≤200

317 stainless steel coil chemical composition

Carbon	Silicon	Sulfur	Phosphorus	Chromium	Molybdenum	Manganese	Nickel	Nitrogen
0.030	0.75	0.030	0.045	18.0-20.0	3.0-4.0	2.00	11.0-15.0	0.10

317stainless steel coil mechanical property

Yield Strengtd 0.2% Offset		Ultimate Tensile Strength		Elongation in 2 in.	Hardness
psi (min.)	(MPa)	psi (min.)	(MPa)	% (min.)	(max.)
30,000	205	75,000	515	40	95 Rockwell B
