Production of all kinds of copper products, high quality, considerate service, contact us. Rich experience in the copper strip industry, cost-effective products, order!
Copper strip is a metal component, product specifications are 0.1 ~ 3 × 50 ~ 250mm various state copper strip products, mainly used in the production of electrical components, lamp heads, battery caps, buttons, seals, connectors, mainly used as electrical conductivity, thermal conductivity, corrosion-resistant equipment. Such as electrical components, switches, gaskets, gaskets, electric vacuum devices, heat sinks, conductive mother materials and automotive water tanks, heat sinks, cylinder pieces and other parts.
| Description | C37000 H62 Brass sheet Coil / C2680 CuZn37 Brass Strip |
|---|---|
| Standards | ASTM, AISI, JIS, SUS, EN, DIN, BS, GB |
| Related Material | T2, T3, TP1, TP2, TU1, TU2,H96, H80, H90, H70, H65, H68,nH62,H59, HP59-1, HMn58-2, HSn62-1, HMn55-3-1, HMn57-3-1,nHAl60-1-1,HAl67-2.5, HAl66-6-3.2, HNi65-5 |
| Specifications | Thick:0.1-8mm,Width:2-2500mm |
| Price Term | EX-Work, FOB, CFR, CIF |
| Payment Term | T/T, L/C, Western Union |
| Delivery Time | According to order' s quantity |
| Package | Export standard package: bundled wooden box or be required;The inner size of container is below:(1)20 foot GP: 5.8m(length)x 2.13m(width)x 2.18m(high)nabout 24-26 CBM(2)40 foot GP: 11.8m(length)x 2.13m(width)x 2.72m(high)nabout 68 CBMWe will packing as the factory, and reach the stander of export.Or as the customer request. In addition,We will make the products with good surface protection. |
| Application | Has a good thermal conductivity, processability, ductility, corrosion resistance and weatherability.nnCan be used in electrical appliances, construction and chemical industry, especially terminal PCB, wire covered with copper belt, air cushion, bus terminalnCan be in auto radiator pipe, snap fastener, camera, radiator, etc.nCan draw to shallow stretch nameplate, badges |
| Attention | As a specialized manufacturer and exporter of thenabove products in china, this collection is the most popularnstyle in our factory, selling fast!We can also produce the stainless steel sheet, bar, pipe,ntube etc.We will give you the bottom price and the fastest speednand then give you the satisfied service for you. |
| Product Name | copper sheet 1 mm Copper Sheet 0.5Mm copper earthing tape |
|---|---|
| Size | Thickness: 0.01-2.0mm; Width: 100mm 200mm 305mm-600mm wide. |
| Length | 1m 2m 3m or in roll |
| MOQ | 10 KG |
| Copper/brass strip material: | H62, H62, H63, H65, H68, H70, H80, H85, H90, H96, T1, T2, T3, C1100, C5111, C5101, C5191, C5210, TU1,TP1,TP2, TAg0.08, TAg0.1, C1100, C1020, C1 201, C1220, C1271, C11000, C2100, C2200, C2300, C2400, C2600, C2680, C2700, C2720,C2800,C2801, etc. |
| Application | Construction filed, Ships building industry, Decoration, Industry,Manufacture,Machinery and hardware fields, Electric etc. |
| Processing Service | Bending, Welding, Decoiling, Cutting, Punching |
| CDA Alloy No. | C10100 | C10200 | C11000 | C15000 | C17200 | C26000 | C51000 |
| Alloy Name | Certified | OFHC | ETP | Zirconium | Beryllium | Cartridge | Phosphor |
| OFHC | Copper | Copper | Copper | Copper | Brass | Bronze | |
| Copper | |||||||
| Chemical Composition (%) | 99.99 Cu | 99.95 Cu | 99.90 Cu | 98.95 Cu | 98.1 Cu | 70 Cu | 94.8 Cu |
| Min. | Min. | Min. | .15 Zr | 1.9 Be | 30 Zn | 5.0 Sn | |
| .04 O | .2 P | ||||||
| Density (lbs./in.³) | 0.323 | 0.323 | 0.323 | 0.321 | 0.298 | 0.308 | 0.32 |
| Electrical Conductivity (% IACS @ 68°F ) | 101 | 102 | 100 | 93 | 22 | 28 | 15 |
| Resistivity (Ω/circ. mil/ft) | 10.3 | 10.3 | 10.3 | 11.2 | 46.2 | 37 | 69.1 |
| Approximate Melting Point (° F ) | 1981 | 1981 | 1981 | 1796 | 1590 | 1680 | 1750 |
| Tensile Strength Hard Temper (kpsi) | 55 | 55 | 55 | 64 | 152 | 109 | 110 |
| Tensile Strength Soft Temper (kpsi) | 34 | 34 | 34 | 30 | 68 | 52 | 51 |
| Yield Strength Hard Temper (kpsi) | 50 | 50 | 50 | 62 | 125 | 68 | 85 |
| Yeild Strength Soft Temper (kpsi) | 11 | 11 | 12 | 13 | 28 | 21 | 21 |
| Elongation Hard Temper (%) | 6 | 6 | 5 | 1.5 | 1 | 5 | 5 |
| Elongation Soft Temper (%) | 36 | 36 | 36 | 30 | 42 | 30 | 49 |
