ASTM TP317L Stainless Steel Pipe | UNS S31703 SS Tube

317L stainless steel tubing is an ultra-low carbon stainless steel with greater fracture stress strength and better ductility than conventional stainless steels, providing resistance to sensitization during the welding process and other heat treatments.317L stainless steel is more resistant to corrosion from sulfuric acid solutions than conventional chromium-nickel stainless steels. Its corrosion resistance increases as the molybdenum content of the alloy increases.317L stainless steel tubes are mainly used in the manufacture of industrial equipment for synthetic fiber, petrochemical, textile, paper and atomic energy reprocessing in corrosion resistant tubes.

Product Details

ASTM TP317L Stainless Steel Pipe | UNS S31703 SS Tube

What is 317l stainless steel tubing?

317L stainless steel tubing is an ultra-low carbon stainless steel with greater fracture stress strength and better ductility than conventional stainless steels, providing resistance to sensitization during the welding process and other heat treatments.317L stainless steel is more resistant to corrosion from sulfuric acid solutions than conventional chromium-nickel stainless steels. Its corrosion resistance increases as the molybdenum content of the alloy increases.317L stainless steel tubes are mainly used in the manufacture of industrial equipment for synthetic fiber, petrochemical, textile, paper and atomic energy reprocessing in corrosion resistant tubes.

Product Introduction of ASTM TP317L Stainless Steel Pipe | UNS S31703 Stainless Steel Pipe

Product Name

ASTM TP317L Stainless Steel Pipe | UNS S31703 Stainless Steel Pipe

Materials

300 Series

Thickness

1.0~40mm

Shape

Round, square, rectangular

Technology

Cold-drawn, hot-rolled, cold-rolled, etc.

Outer diameter

3.0-325mm

Certificate

ISO

Length

6m,5.8m,8m,11.8m,12m or as required

Packing

Standard packaging or customer requirements

Payment

30% despoit in advance,the 70% balance against B/L copy,or other.

Technical Data Sheet of Stainless Steel Pipe & Tube:

Standard

AISI,ASTM,DIN,EN,JIS,GB.
ASTM A240/ASME SA-240、ASTM A276、ASTM A182/ASME SA-182、ASTM A312/ASMES A312
ASTM B625/ASME B625、ASTM B673/ASME B673

Available Grades

Stainless steel 301 / 302 / 303 / 304 / 304L / 310S / 316L / 316Ti / 316LN / 317L / 904L / 2205 / 2507 / 321 / 32760 / 253MA / 254SMo / 410 / 420 / 430 / Custom465 / XM-19 / S31803 / S32750 / S32205 / F50 / F60 / F55 / F60 / F61 / F65.
Nitronic 30 / Nitronic 32 / Nitronic 33 / Nitronic 40 / Nitronic 50 / Nitronic 60  etc.

Monel 400 / Monel K-500

Inconel 600 / Inconel 601 / Inconel 625 / Inconel 617 / Inconel 690 / Inconel 718 / Inconel X-750 / Inconel 713C / Inconel 713LC

Incoloy A-286 / Incoloy 800 / Incoloy 800H / Incoloy 800HT

Incoloy 825 / Incoloy 901 / Incoloy 925 / Incoloy 926

Nimonic 75 / Nimonic 80A / Nimonic 90 / Nimonic 105 / Nimonic C263 / L-605

Hastelloy B / Hastelloy B-2 / Hastelloy B-3 / Hastelloy C / Hastelloy C-276 / Hastelloy C-22

Hastelloy C-4 / Hastelloy C-2000 / Hastelloy G-35 / Hastelloy X / Hastelloy N

PH stainless steel 15-5PH / 17-4PH / 17-7PH

Out diameter

Seamless Pipe 6MM - 1174MM or customized

Thickness

Seamless Pipe 1mm - 80mm or customized

Max Length

Seamless Pipe 12000mm or customized

Finish

2B, Pickling, Polished, Brushed, Sandblast, BA, EP

Packing

waterproof polybag, wooden box, end cap, wooden crame/pallet

Inspection

TUV,SGS,BV,ABS,LR and so on

Application

Chemical, pharmaceutical and biomedical, petrochemical and refining, environment, food processing, aviation, fertilizer, sewage treatment, desalination, waste incineration, etc.

Processing Services

Machining: Turning/milling/planing/drilling/boring/grinding/gear cutting/CNC machining

Deformation processing: bending/cutting/rolling/stamping

Welded

Forging

Delivery time

7-40 days

Terms of Trade

FOB CIF CFR CIP DAP DDP EXW

Payments

T/T, L/C,D/A,D/P, Western Union,MoneyGram,Payment of offline orders according to customer requirements.

Transport

Air, sea, train, truck

Sample

Free

Warranty Policy

Trade Assurance After Sales Service

chemical composition of ASTM TP317L Stainless Steel Pipe | UNS S31703 SS Tube

Chemical Material Composition of SS 317/317L seamless pipes
Grade Ni Mn P C S Si Cr Mo N
317 11 – 14 2 max 0.040 max 0.08 max 0.03 max 1 max 18 – 20 3 – 4

mechanical property of ASTM TP317L Stainless Steel Pipe | UNS S31703 SS Tube

SS 317 Seamless Pipes Mechanical Properties
Density 8.0 g/cm3
Melting Point 1454 °C (2650 °F)
Tensile Strength Psi – 75000 , MPa – 515
Yield Strength (0.2%Offset) Psi – 30000 , MPa – 205
Elongation 35%
