316 stainless steel pipe is safe, reliable, hygienic, environmentally friendly, economical and applicable; the successful development of thin-walled pipe and the new reliable, simple and convenient connection method make it have more irreplaceable advantages of other pipes.
Stainless steel 316 offers several advantages and benefits, and it is perfect for medical, pharmaceutical, and marine applications. It is also very resistant to chlorides and salt.
This grade’s high level of chromium and nickel gives it superior resistance to acids and chlorides. It can also withstand caustic solutions and strong disinfectants. It is also very resistant to aluminum chloride corrosion. This grade of steel has a lower melting point.
Another critical factor to consider when choosing stainless steel is the presence of molybdenum. This element can enhance the resistance of 316 stainless steel to chloride corrosion. The presence of molybdenum also increases its longevity. Another benefit to a 316 stainless steel pipe is that it is primarily non-magnetic. It can be quickly processed to create different shapes.
Technical Data Sheet of Stainless Steel Pipe & Tube | |
Product Name | ASTM A312 316 (EN 1.4401, UNS S31600) Stainless Steel Seamless Pipes & Tubes |
Equivalent Materials | Grade 316, UNS S31600, EN 1.4401, AISI 316, X5CrNiMo17-12-2 |
Type | Seamless |
Shape | Square / Rectangular / Round |
Standard | GB,AISI,ASTM,DIN,EN,JIS ASTM A240/ASME SA-240、ASTM A276、ASTM A182/ASME SA-182、ASTM A312/ASMES A312 ASTM B625/ASME B625、ASTM B673/ASME B673 |
Available Grades | Stainless steel 301 / 302 / 303 / 304 / 304L / 310S / 316L / 316Ti / 316LN / 317L / 904L / 2205 / 2507 / 321 / 32760 / 253MA / 254SMo / 410 / 420 / 430 / Custom465 / XM-19 / S31803 / S32750 / S32205 / F50 / F60 / F55 / F60 / F61 / F65. Nitronic 30 / Nitronic 32 / Nitronic 33 / Nitronic 40 / Nitronic 50 / Nitronic 60 etc. |
Monel 400 / Monel K-500 | |
Inconel 600 / Inconel 601 / Inconel 625 / Inconel 617 / Inconel 690 / Inconel 718 / Inconel X-750 / Inconel 713C / Inconel 713LC | |
Incoloy A-286 / Incoloy 800 / Incoloy 800H / Incoloy 800HT | |
Incoloy 825 / Incoloy 901 / Incoloy 925 / Incoloy 926 | |
Nimonic 75 / Nimonic 80A / Nimonic 90 / Nimonic 105 / Nimonic C263 / L-605 | |
Hastelloy B / Hastelloy B-2 / Hastelloy B-3 / Hastelloy C / Hastelloy C-276 / Hastelloy C-22 | |
Hastelloy C-4 / Hastelloy C-2000 / Hastelloy G-35 / Hastelloy X / Hastelloy N | |
PH stainless steel 15-5PH / 17-4PH / 17-7PH | |
Out diameter | Seamless Pipe 6MM - 1174MM or customized |
Thickness | Seamless Pipe 1mm - 80mm or customized |
Max Length | Seamless Pipe 12000mm or customized |
Finish | 2B, Pickling, Polished, Brushed, Sandblast, BA, EP |
Packing | waterproof polybag, wooden box, end cap, wooden crame/pallet |
Inspection | TUV,SGS,BV,ABS,LR and so on |
Application | Chemical, Pharmaceutical & Bio-Medical, Petrochemical & Refinery, Environmental, Food Processing, Aviation, Chemical Fertilizer, Sewage Disposal, Desalination, Waste Incineration etc. |
Processing Service | Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining |
Deformation processing : Bending / Cutting / Rolling / Stamping | |
Welded | |
Forged | |
Delivery Time | 7-40 days |
Trade Term | FOB CIF CFR CIP DAP DDP EXW |
Payment | T/T, L/C,D/A,D/P, Western Union,MoneyGram,According to customer requirements payments for offline orders. |
Transportation | By air, by sea, by train, by truck |
Sample | Free |
Warranty | Trade assurance after sales service |
Material | 201 304L 316 316L 316Ti 321 309S 310S 317L 347H 2205 2507 904L |
Thinckness | 1.73mm-59.54mm |
Outer diameter | 10.3mm-1219.0mm |
Length | 6m or as customer's requirement |
Finish | Polished, Pickled,hairline,mirror |
Shape | Round,square, rectangular,oval |
Technology | Seamless,weld |
Standard | JIS, AISI, ASTM, GB, DIN, EN ,etc. |
MOQ | 1Ton |
Application | Decoration, industry, etc. |
Certificate | SGS |
Packaging | Standard exporting packing |
Chemical Properties of Frequently-used Stainless Steel Material Grade | |||||||||||
UNS | ASTM | EN | JIS | C% | Mn% | P% | S% | Si% | Cr% | Ni% | Mo% |
S20100 | 201 | 1.4372 | SUS201 | ≤0.15 | 5.5-7.5 | ≤0.06 | ≤0.03 | ≤1.00 | 16.0-18.0 | 3.5-5.5 | - |
S20200 | 202 | 1.4373 | SUS202 | ≤0.15 | 7.5-10.0 | ≤0.06 | ≤0.03 | ≤1.00 | 17.0-19.0 | 4.0-6.0 | - |
S30100 | 301 | 1.4319 | SUS301 | ≤0.15 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.00 | 16.0-18.0 | 6.0-8.0 | - |
S30400 | 304 | 1.4301 | SUS304 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-10.5 | - |
S30403 | 304L | 1.4306 | SUS304L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 8.0-12.0 | - |
S30908 | 309S | 1.4833 | SUS309S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 22.0-24.0 | 12.0-15.0 | - |
S31008 | 310S | 1.4845 | SUS310S | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤1.50 | 24.0-26.0 | 19.0-22.0 | - |
S31600 | 316 | 1.4401 | SUS316 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
S31603 | 316L | 1.4404 | SUS316L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 |
S31703 | 317L | 1.4438 | SUS317L | ≤0.03 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 18.0-20.0 | 11.0-15.0 | 3.0-4.0 |
S32100 | 321 | 1.4541 | SUS321 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-12.0 | - |
S34700 | 347 | 1.4550 | SUS347 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.03 | ≤0.75 | 17.0-19.0 | 9.0-13.0 | - |
S40500 | 405 | 1.4002 | SUS405 | ≤0.08 | ≤1.00 | ≤0.04 | ≤0.03 | ≤1.00 | 11.5-14.5 | ≤0.60 | - |
S40900 | 409 | 1.4512 | SUS409 | ≤0.08 | ≤1.00 | ≤0.045 | ≤0.03 | ≤1.00 | 10.5-11.75 | ≤0.50 | - |
S43000 | 430 | 1.4016 | SUS430 | ≤0.12 | ≤1.00 | ≤0.040 | ≤0.03 | ≤0.75 | 16.0-18.0 | ≤0.60 | - |
S43400 | 434 | 1.4113 | SUS434 | ≤0.12 | ≤1.00 | ≤0.040 | ≤0.03 | ≤1.00 | 16.0-18.0 | - | - |
S44400 | 444 | 1.4521 | SUS444L | ≤0.025 | ≤1.00 | ≤0.045 | ≤0.03 | ≤1.00 | 17.5-19.5 | ≤1.00 | - |
S40300 | 403 | - | SUS403 | ≤0.15 | 5.5-7.5 | ≤0.04 | ≤0.03 | ≤0.50 | 11.5-13.0 | ≤0.60 | - |
S410000 | 410 | 1.40006 | SUS410 | ≤0.15 | ≤1.00 | ≤0.035 | ≤0.03 | ≤1.00 | 11.5-13.5 | ≤0.60 | ≤1.00 |
S42000 | 420 | 1.4021 | SUS420J1 | 0.16~0.25 | ≤1.00 | ≤0.04 | ≤0.03 | ≤1.00 | 12.0-14.0 | ≤0.75 | ≤1.00 |
S440A | 440A | 1.4028 | SUS440A | 0.60~0.75 | ≤1.00 | ≤0.04 | ≤0.03 | ≤1.00 | 16.0-18.0 | - | ≤0.75 |
S32750 | SAD2507 | 1.4410 | ≤0.03 | ≤1.2 | ≤0.035 | ≤0.02 | ≤0.80 | 24.0-26.0 | 6.0-8.0 | 3.0-5.0 | |
S31803 | SAF2205 | 1.4462 | ≤0.03 | ≤2.0 | ≤0.03 | ≤0.02 | ≤1.00 | 21.0-23.0 | 4.0-6.5 | 2.5-3.5 | |
N08904 | 904L | 1.4539 | ≤0.0.3 | ≤2.0 | ≤0.035 | ≤0.03 | ≤1.00 | 18.0-20.0 | 23.0-25.0 | 3.0-4.0 |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | |
316 | Min | - | - | - | 0 | - | 16 | 2 | 10 | - |
Max | 0.08 | 2 | 0.75 | 0.045 | 0.03 | 18 | 3 | 14 | 0.1 |
Grade | Tensile Str | Yield Str | Elong | Hardness | |
(MPa) min | 0.2% Proof | (% in 50mm) min | |||
(MPa) min | Rockwell B (HR B) max | Brinell (HB) max | |||
316 | 515 | 205 | 40 | 95 | 217 |
