5052 aluminum sheet description

5052 aluminum plate for the AL-Mg system alloy aluminum plate, magnesium is the main alloy element in 5052 alloy aluminum plate, is the most widely used a rust-proof aluminum, this alloy has high strength, especially fatigue strength: plasticity and corrosion resistance, can not be heat-treated to strengthen, plasticity is still good when semi-cold work hardening, plasticity is low when cold work hardening, good corrosion resistance, good weldability, poor machinability, polishable.

Product Details

5052 aluminum sheet Process properties

  1. arrow icon(1) Forming properties:①The alloy has good plasticity in the hot state process. The forging and die forging temperature is 420~475°C, and the deformation rate is 80% in this temperature range.The cold stamping performance is related to the state of the alloy. The cold stamping performance is good in the annealed (O) state, followed by the H32 and H34 states, and not good in the H36/H38 state.
  2. arrow icon(2) Welding performance:①The alloy's gas welding, arc welding, resistance welding, spot welding, seam welding performance is good, two argon arc welding crystallization cracking tendency. Hard brazing performance is still good, while the soft brazing performance is poor.② high strength and plasticity of the weld, the strength of the weld up to 90% to 95% of the base metal strength. However, the weld is not high gas tightness, and it is recommended to use 5A03 alloy as solder, which can improve its gas tightness and eliminate the tendency of cracking.
  3. arrow icon(3) Mechanical processing performance:The cutting performance of the alloy is not good in the annealed state, but it is improved in the cold hardened state.

Aluminium plate specification

ItemAluminium sheet ,Aluminium plate, Aluminium alloy sheet, Aluminium alloy plate
StandardGB/T3190-2008,GB/T3880-2006,ASTM B209,JIS H4000-2006,etc
Grade1000, 2000, 3000, 4000, 5000, 6000series a) 1000 Series: 1050, 1060, 1070, 1100, 1200, 1235, etc. b) 2000 Series: 2014, 2024, etc. c) 3000 Series: 3003, 3004, 3005, 3104, 3105, 3A21, etc. d) 4000 Series: 4045, 4047, 4343, etc. e) 5000 Series: 5005, 5052, 5083, 5086, 5154, 5182, 5251, 5454, 5754, 5A06, etc. f) 6000 Series: 6061, 6063, 6082, 6A02, etc.
Thickness0.1mm-200mm
Width2mm-2200mm
Length1-12m or as required
Temper0-H112,T3-T8, T351-851
Surfacemill, bright, polished, hair line, brush,sand blast, checkered,embossed, etching,etc
Aplication1)Further making utensil2)Solar reflective film3)The appearance of the building4)Interior decorating; ceilings, walls,etc5)Furniture cabinets6)Elevator decoraction7)Signs, nameplate,bags making8)Decorated inside and outside the car9)Household appliances:refrigerators, microwave ovens, audio equipment,etc
